Chapter 5 Troubleshooting
A404/A405: Calibration
SuperLoader User’s Guide 189
14 Forward and Backward Offset of Calibration Tracks too Far
Apart
13 Backward Offset of Calibration Tracks too Far Apart
12 Forward Offset of Calibration Tracks too Far Apart
11 Bottom Edge of Tape Found too Far From Bottom Head Stop
location
10 Amplitude Calibration low
09 No Write Gate
08 2F Amplitude Out of Specification
07 Write Current Out of Specification
06 Resolution Calculation Failed
05 Tension Calculation Failed
04 Bottom Edge of Tape Not Found
03 Bottom Edge of Tape too Close to Bottom head Stop location
02 Width of a Calibration Track Out of Specification (any one of
the calibration tracks)
01 Media type Unknown
00 Number of Calibration Tracks Inconsistent with Media Type
Cal Info Flags: Used to help verify the media type and the format of that media that was
inserted as to what the user had expected to use. This is another verification to determine if it is
media or a user induced failure. Calibration Tracks Successfully Found.
Bit
Description
15 Unused (DLT2000/4000 only) Current Calibration is in
Azimuth Mode (DLT 7000/8000 only)
Field Description
