Safran SecureSync 2400 - Reviewing the GNSS Reference Status

To access the GNSS Receiver settings:
1.
Navigate to INTERFACES > REFERENCES: GNSS 0.
Note: Typically, there will be only one GNSS reference,
numbered "0".
2.
The GNSS 0 status window will open. To open the configuration window,
click Edit in the bottom-left corner.
OR:
1.
Navigate to INTERFACES > REFERENCES: GNSS Reference.
2. Click on the INFO button, or the GEAR button to configure the GNSS set-
tings, or review GNSS reference status information.
3.3.3.1 Reviewing the GNSS Reference Status
To view the current status of your GNSS reference:
1.
Navigate to INTERFACES > REFERENCES: GNSS Reference.
2.
Click the INFO button next to GNSS 0. The GNSS 0 status window will dis-
play; it contains two tabs, explained in detail below: Main [= default], and
Satellite Data.
The "Main" tab
