Safran SecureSync 2400 - Alarm Relay out [1204-0 F]

Time-to-first-fix (Timing): Several seconds (the PPS pulse will become
available once the positioning fix has been obtained)
Jamming resilience: Signal is 30 to 40 dB stronger than GPS signal
Spoofing resilience: Encrypted signal
Maximum number of cards: 1
Ordering information:
STL module: 1204-3E
STL subscription (1 year): STL-SS-1Y
Figure 5-58: Model 1204-3E option card rear plate
5.2.7.2 Alarm Relay Out [1204-0F]
The Model 1204-0F Alarm Relay Option Card provides three (3) configurable
relay outputs for the SecureSync platform.
Alarm Relay Out [1204-0F]: Specifications
Inputs/Outputs: (3) three contact relay connections (NC, common, NO)
Signal Type and Connector: Terminal block
Contacts switch under max. load of 30VDC, 2A
Contacts rated to switch: 220VDC
Nominal Switch Capacity: 30V, 2A
Maximum switch voltage: 220VDC
Maximum switch power: 60W
Maximum switch current: 2A
Breakdown voltage: 1000VDC between contacts
SecureSync 2400 User Manual 527
APPENDIX
