5.2.4 Telecom Option Cards
This section contains technical information and Web UI procedures relevant to
SecureSync option cards commonly used in the telecommunications industry.
5.2.4.1 T1/E1 Out [1204-09, -0A, -4C, -53]
The 1204-09 and 1204-0A E1/T1 option card provide 1.544MHz or 2.048MHz and
E1 or T1 data outputs for the SecureSync platform. The 1204-4C and 1204-53
E1/T1 option cards each provide (4) E1 or T1 data outputs (but do not include a
clock output).
SecureSync meets G.812 TypeI when installed with a Rubidium option, and G.811
when installed with a Rubidium option and synchronized with GNSS.
Note: Rubidium oscillators are recommended for the E1/T1 option
cards.
Model 1204-09 E1/T1 (75 Ω): Specifications
Outputs:
(1) 1.544/2.048MHz Output
(2) Unbalanced E1/T1 Outputs
T1 mode:
1.544 MHz (square wave) frequency output
(2) 1.544 Mb/sec data rate outputs:
Outputs are DS1 framed all ones
Supports Super Frame (SF or D4) and Extended Super Frame
(ESF)
SSM support
