Board temperature (measured on the main board, sometimes also
referred to as 'System temperature')
CPU temperature
Note: Oscillator temperature is plotted over time in the
History panel on the right, while graphs for board and
CPU temperature can be found under TOOLS > SYSTEM:
System Monitor.
Last Time Reference Change: [Timestamp: Last occurrence]
Last 1PPS Reference Change: [Timestamp: Last occurrence]
Last TFOM Change: [Timestamp: Last occurrence]
Last Sync State Change: [Timestamp: Last occurrence]
Last Holdover State Change: [Timestamp: Last occurrence]
The Oscillator History Panel
The Oscillator History Panel offers real- time graphical monitoring of
SecureSync’s internal timing. The following graphs plot key oscillator-relevant
data over time::
Phase Error Magnitude: See 1PPS Phase Error
Frequency Error: See 10_MHz_Frequency_Error
Scaled DAC Value: See DAC Step
Oscillator Temperature, which has an effect on oscillator accuracy, and
therefore can be used to interpret oscillator performance.
You can zoom in on any of the graphs by grabbing the handles at either end and
pulling them inwards. The graph will focus in on the time interval you choose in
real time.
Clicking on the Delete icon in the top-right hand corner will erase all current oscil-
lator log data.
Clicking on the Download arrow icon will download the latest oscillator log data
as a .csv file.
3.5.4 Oscillator Logs
To export, or delete the oscillator logs:
1.
Navigate to MANAGEMENT > OTHER: Disciplining.
3.5 Managing the Oscillator
CHAPTER 3 • SecureSync 2400 User Manual Rev. 5.2
257
