2.15.16 Safran Technical Support for NTP
Safran does not provide technical assistance for configuring and installing NTP
on Unix-based applications. Please refer to www.ntp.org for NTP information and
FAQs. Another helpful source is the Internet newsgroup at
news://comp.protocols.time.ntp.
Safran can provide support for Microsoft
®
Windows-based time synchronization:
https://safran- navigation- timing.com/document/synchronizing- windows-
computers/. See safran-navigation-timing.com for additional information, or con-
tact Safran Technical Support.
2.16 Configuring PTP
Note: These instructions refer to the PTP available directly through
your unit via ETH0 and ETH1.
If you have a 1204-32 Grandmaster PTP option card installed, you will
need to follow separate instructions to configure that PTP func-
tionality. See "PTP Grandmaster [1204-32]" on page499
Precision Time Protocol (PTP) is a time protocol that can be used to synchronize
computers on an Ethernet network. SecureSync supports PTP Version2, as spe-
cified in the IEEE 1588-2008 standard, via two (2) Ethernet ports.
SecureSync can be configured as a PTP Master Clock or as a PTP Slave Clock.
Next to PTP specifications, this topic describes the PTP menu items and settings,
and outlines how to set up SecureSync as a PTP Master or Slave.
PTP Specifications
Inputs/Outputs: (2) Ports
Signal Type: Ethernet
Management: Web UI
Network Speeds: 10/100/1000 Mb/s
PTP Version supported:PTP2 (IEEE 1588-2008)
PTP Profiles supported: (Changing the profile selection will adjust the
default settings for the port to be configured):
2.16 Configuring PTP
CHAPTER 2 • SecureSync 2400 User Manual Rev. 5.2
149
