Steps 4 through 10 of this installation procedure should only be per-
formed if your installation location or card requires it.
5.2.2.7 [4]: Slot 1 & 2 Installation
Option cards installed in Slot 1 or Slot 2 sit on top of and are screwed into pre-
installed standoffs and plug in to the unit through the included ribbon cable.
Instructions for installing an option card into one of the slots above the CPU
board (1 or 2):
a. Safely power down the SecureSync unit and remove the top cover of the
main chassis (housing). Save the screws.
b.
DANGER! SecureSync does not have an ON/OFF switch. You
must unplug the machine to remove power!
Caution: NEVER install an option card from the rear of the unit,
ALWAYS from the top, after removing the chassis cover.
c. Unscrew and remove the blank option card plate from the back of the unit
(or the existing option card). Save the screws.
d. Insert option card into the slot, lining up the screw holes on the card with
the standoffs..
374 SecureSync 2400 User Manual
APPENDIX
