Coded Expression: Defines the data structure of the IRIG signal, where:
BCD = Binary Coded Decimal
TOY = Time of Year
CF = Control Field
SBS = Straight Binary Seconds
The possible values will vary according to the values of Format and
Modulation Type
Message: The IRIG message of the output.
For IRIG frequency and output specifications, see "IRIG Standards and Spe-
cifications" on page587.
5.2.5.3 STANAG Out [1204-11, -25]
The STANAG Output option card models 1204-11 and 1204-25 provide (2) con-
figurable STANAG outputs and (1) 1PPS output for the SecureSync platform.
STANAG Out [1204-11, -25]: Specifications
Outputs: (2) STANAG Outputs, (1) 1PPS Output
Signal Type and Connector: 5V or 10V or RS-485 level (user selectable)
for STANAG and 1PPS output. DB-25 connector.
Formats Supported:
STANAG 4246 HAVE QUICK I
STANAG 4246 HAVE QUICK II
STANAG 4372 HAVE QUICK IIA
STANAG 4430 Extended HAVE QUICK
STANAG 4430 Standard Time Message (STM)
ICD-GPS-060A BCD Time Code
ICD-GPS-060A HAVE QUICK
DOD-STD-1399 BCD Time Code
Programmable Pulse Width (1PPS Output): 100ns to 500ms with 20ns
resolution
