Caution: Ensure that the ribbon cable is aligned and fastened
properly to all pins on the connector of the card, before power-
ing the unit up, to avoid damage to the equipment.
5.2.2.8 [5]: Bottom Slot Installation
Instructions for installing an option card into one of the bottom slots (3, or 5):
a. Safely power down the unit and remove the top cover of the main chassis
(housing). Save the screws.
DANGER! SecureSync does not have an ON/OFF switch. It is
necessary to unplug the machine to remove power!
Caution: NEVER install an option card from the rear of the unit,
ALWAYS from the top, after removing the chassis cover.
b. Remove the blank option card plate, or the existing option card in the slot.
Save the screws.
If a card is populating the slot above the bottom slot your option card is to
be installed into, remove it temporarily (also remove and save the standoffs
for reuse).
c. Insert the card into the bottom slot by carefully pressing its connector into
the extension board connector (see Figurebelow), and by lining up the
screw holes on the card with the screw holes on the chassis.
