1PPS
TTS
CTCSS
Signal protocol:
ASCII time code
IRIG
STANAG
Have Quick
E1/T1 data
Telecom timing, etc.
Ethernet (NTP, PTP)
Time code I/O
Alarm out, etc.
Functionality:
Networking card (incl. NTP, PTP)
Time code I/O
Alarm output
Special functionality e.g., revertive selector, bidirectional com-
munication
Connector type:
BNC
DB-9/25
Terminal block
RJ-12/45
SFP
ST fiber optic
To visually identify an option card installed in your unit, or to obtain an over-
view which option cards are available for SecureSync, see "Option Cards Over-
view" on the facing page.
To obtain detailed information on a specific option card, using its ID number, see
"Option Card Identification" on page20.
To locate option card topics in this manual by their heading or functionality, see
"Option Cards" on page361. This Chapter also includes information on field
installation and Web UI functionality.
16
CHAPTER 1 • SecureSync 2400 User Manual Rev. 5.2
