Function Web UI Name Illustration ID* Inputs Outputs Conn.'s
ASCII Time
Code RS-
232
ASCII Time-
code RS-232
02
1 RS-232 (1x) DB-9
(2x)
ASCII Time
Code RS-
485
ASCII Time-
code RS-485
04
1 1 Terminal
block,
10-pin
IRIG BNC IRIG In/Out
BNC
05
1 2 BNC
(3x)
IRIG Fiber
Optic
IRIG In/Out,
Fiber
27
1 2 ST Fiber
optic
(3x)
IRIG out,
BNC
IRIGOut BNC
15
0 4 BNC
(4x)
IRIG out,
fiber optic
IRIG Out, Fiber
1E
0 4 ST Fiber
optic
(4x)
IRIG out,
RS-485
IRIGOut, RS-
485
22
0 4 Terminal
block,
10-pin
STANAG
input
STANAG In
1D
2x 1x DB-25
(1x)
STANAG
in, isol.
STANAG In, Isol-
ated
24
2x 1x DB-25
(1x)
STANAG
out
STANAG Out
11
0 2x
STANAG,
1x 1PPS
DB-25
(1x)
STANAG
out, isol.
STANAG Out,
Isolated
25
0 2x
STANAG,
1x 1PPS
DB-25
(1x)
HAVE
QUICK out
BNC
HAVE QUICK
Out, BNC
10
0 4 (TTL) BNC
(4x)
HAVE
QUICK out
RS-485
HAVE QUICK
Out, RS-485
1B
0 4 Terminal
block,
10-pin
HAVE
QUICK
HAVE QUICK
29
1 3 BNC
(4x)
Networking Cards
1Gb PTP:
Master
only
Gb PTP
32
0 1PPS (1x
BNC), SFP
(1x)
BNC
(1x), SFP
(1x)
1.5 Option Cards
