information about the current time and synchronization reference selected by
the SecureSync device.
PTP Grandmaster [-32]: Specifications
Inputs/Outputs: (1) Configurable as Input or Output
Signal Type and Connector: Ethernet via SFP, and 1PPS Output via BNC
Management: Web UI
Resolution: 8ns (±4ns) packet time stamping resolution
Accuracy: 30ns accuracy (3σ) Master to Slave, via crossover cable
Network Speeds: 100 Mb/s, or 1Gb/s, depending on SFP module used
PTP Version supported:PTP2 (IEEE 1588-2008)
PTP Profiles supported: Default, Telecom, Enterprise
Transmission modes: Unicast [default], Multicast
Maximum Number of Cards: 6
Ordering Information: 1204-32: PTP/Precision Timing Protocol Option
Module
Figure 5-56: Model 1204-32 option card rear plate
PTP Grandmaster [-32]: Edit Window
1.
To configure this option card, go to its Edit window. For instructions, see
"Configuring Option Card Inputs/Outputs" on page364.
