Green=Connected. The speed of the connection is indicated.
Orange=Not connected.
Port State: Reports the current state of the PTP State Machine:
Disabled: PTP Ethernet port is Disabled. See PTP Setup/Network
page, PTP Network Settings options.
Initializing: Ethernet link is unplugged/PTP Module is in power-up
state. A Master Clock doesn’t leave this state while it can’t get the cur-
rent time and synchronization references from the SecureSync to syn-
chronize with it.
Listening: PTP module is looking for a Master Clock.
Master: PTP Master has become the active Master Clock on the net-
work.
Passive: PTP Module has become a Passive Master Clock. (There is
another Master Clock on the network with better quality or higher pri-
ority). This Master will wait until the Best Master Clock Algorithm
determines it should become the best Master Clock, and then it will
transition to the Master Clock state.
Uncalibrated: PTP Slave has selected a Master Clock on the network
attempts to synchronize with it using sync packets.
Number of Unicast Slaves: Number of PTP Slaves that have been granted
by the PTP Master to run in unicast mode (maximum = 4000 unicast con-
tracts)
Profile: Whether the profile is the default or Telecom.
Domain Number: The current PTP Domain Number.
Clock Mode: See "Main tab settings" on page502.
Current IP Address: The IP address currently being used by the PTP inter-
face.
MAC Address: The MAC address currently being used by the PTP interface.
Advanced tab: Status information
508 SecureSync 2400 User Manual
APPENDIX
