Note: Format 2 cannot be configured for a Time Zone Offset or with
automatic Daylight Saving Time adjustment. Attempting to configure
a Local clock using Data Format 2 with either a Time Zone Offset or
automatic DST rule will result in an error message.
E x a m p l e m e s s a g e :
CR LF IQYY ^ DDD ^ HH:MM:SS.SSS ^ LD
Where:
CR Carriage Return
LF Line Feed
I Time Sync Status (space, ?, *)
Q Quality Indicator (space, A, B, C, D)
YY Year without century (99, 00, 01, etc.)
^ Space separator
DDD Day of Year (001-366)
HH Hours (00-23 UTC time)
: Colon separator
MM Minutes (00-59)
: Colon separator
SS (00-60)
. Decimal separator
SSS Milliseconds (000-999)
L Leap Second indicator (space, L)
D Daylight Saving Time Indicator (S,I,D,O)
The leading edge of the first character (CR) marks the on-time point of the data
stream.
The time synchronization status character (I) is defined as described below:
