SINAMICS G120 Control Units CU240B-2/CU240E-2
314 List Manual (LH11), 01/2016, A5E33839529
Description: Sets the DC link voltage threshold value for the following messages:
"Vdc_act <= Vdc_threshold p2172" (BO: r2197.9)
"Vdc_act > Vdc_threshold p2172" (BO: r2197.10)
Dependency: Refer to: p2173
Description: Sets the delay time for the comparison of the DC link voltage r0070 with the threshold value p2172.
Dependency: Refer to: p2172
Description: Sets the torque threshold value for the messages:
"Torque setpoint < torque threshold value 1 and n_set reached" (BO: r2198.9)
"Torque setpoint < torque threshold value 1" (BO: r2198.10)
"Torque setpoint > torque threshold value 1" (BO: r2198.13)
Dependency: Refer to: p2195, r2198
Description: Sets the speed threshold for the message "Motor blocked" (BO: r2198.6).
Dependency: Refer to: p0500, p2177, r2198
Refer to: F07900
Note: The following applies for encoderless vector control for induction motors:
At low speeds in open-loop speed controlled operation (see p1755, p1756), a blocked motor cannot be detected.
The following applies for encoderless vector control for permanent magnet synchronous motors:
At low speeds in open-loop speed controlled operation (see p1755, p1756), a blocked motor can only be detected if
p2175 = p1755, and p1750.6 is set to 1.
p2172[0...n] DC link voltage threshold value / Vdc thresh val
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: p2001 Dyn. index: DDS, p0180
Unit group: 5_2 Unit selection: p0505 Func. diagram: -
Min Max Factory setting
0 [V] 2000 [V] 800 [V]
p2173[0...n] DC link voltage comparison delay time / t_del Vdc
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: U, T Scaling: - Dyn. index: DDS, p0180
Unit group: - Unit selection: - Func. diagram: -
Min Max Factory setting
0 [ms] 10000 [ms] 10 [ms]
p2174[0...n] Torque threshold value 1 / M_thresh val 1
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: U, T Scaling: - Dyn. index: DDS, p0180
Unit group: 7_1 Unit selection: p0505 Func. diagram: 8012
Min Max Factory setting
0.00 [Nm] 20000000.00 [Nm] 5.13 [Nm]
p2175[0...n] Motor blocked speed threshold / Mot lock n_thresh
Access level: 3 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: U, T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 8012
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 120.00 [rpm]
