SINAMICS G120 Control Units CU240B-2/CU240E-2

List Manual (LH11), 01/2016, A5E33839529

2 Parameters

2.2 List of parameters

Description: Displays the rated motor stator resistance at rated temperature (total of p0625 and p0627).

Dependency: Refer to: p0627

Note: The parameter is not used for synchronous motors (p0300 = 2xx).

Description: Displays the motor rotor resistance at an ambient temperature p0625.

Dependency: Refer to: p0625

Note: The parameter is not used for synchronous motors (p0300 = 2xx).

Description: Displays the nominal rotor resistance of the motor at the rated temperature.

The rated temperature is the sum of p0625 and p0628.

Dependency: Refer to: p0628

Note: The parameter is not used for synchronous motors (p0300 = 2xx).

Description: Displays the stator leakage inductance of the motor including the motor reactor (p0233).

Description: Displays the stator longitudinal inductance of the synchronous motor including the motor reactor (p0233).

r0373[0...n] Motor rated stator resistance / Mot R_stator rated

Access level: 4 Calculated: - Data type: FloatingPoint32

Can be changed: - Scaling: - Dyn. index: MDS
