3 Function diagrams
3.14 Vector control, Standard Drive Control (p0096 = 1)
SINAMICS G120 Control Units CU240B-2/CU240E-2
688 List Manual (LH11), 01/2016, A5E33839529
3.14 Vector control, Standard Drive Control (p0096 = 1)
Function diagrams
6850 – U/f control, overview (p0096 = 1) 689
6851 – U/f characteristic and voltage boost (p0096 = 1) 690
6853 – Resonance damping and slip compensation (U/f) (p0096 = 1) 691
6854 – Vdc_max controller and Vdc_min controller (U/f) (p0096 = 1) 692
6856 – Interface to the Power Module (p0096 = 1) 693
