3 Function diagrams 3.7 Internal control/status words
SINAMICS G120 Control Units CU240B-2/CU240E-2
622 List Manual (LH11), 01/2016, A5E33839529
Fig. 3-55 2537 – Status word monitoring functions 3 (r2199)
- 2537 -
Function diagram
87654321
fp_2537_97_63.vsd
Internal control/status words
G120 CU240B/E-2
09.12.2015 V4.7.6
Status word, monitoring functions 3 (r2199)
11
12
13
14
15
PROFIdrive-Bit
9
10
8
7
6
5
4
3
2
1
0
r2199.11
r2199.5
r2199.1
r2199.0
<1>
[8012.1], [8023.1]
r2199.4
From speed signals
n_act = smoothed speed actual value r2169 [8010.2].
Status word, monitoring functions 3 (r2199)Bit No.
1 = |n_act| < speed threshold value 3 (p2161)
1 = f or n comparison value reached or exceeded (p2141)
1 = Speed setpoint - actual value deviation within tolerance t_on
1 = Ramp-up/ramp-down completed
1 = Torque utilization < torque threshold value 2 (p2194)
ZSW monitor 3
r2199
r2199
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
[8010.8]
From speed signals
[8011.8]
From speed signals
[8011.8]
From speed signals
[8010.8]
From speed signals
[8012.5]
Reserved
<1>
