SINAMICS G120 Control Units CU240B-2/CU240E-2
List Manual (LH11), 01/2016, A5E33839529
773
4 Faults and alarms
4.1 Overview of faults and alarms
4.1.3 Number ranges of faults and alarms
Faults and alarms are organized into the following number ranges:
Note
The following number ranges represent an overview of all faults and alarmsused in the
SINAMICS drive family.
The faults and alarms for the product described in this List Manual are described in detail in
"List of faults and alarms" (Page 775).
Table 4-5 Number ranges of faults and alarms
of To Area
1000 3999 Control Unit
4000 4999 Reserved
5000 5999 Power section
6000 6899 Infeed
6900 6999 Braking Module
7000 7999 Drive
8000 8999 Option Board
9000 12999 Reserved
13000 13020 Licensing
13021 13099 Reserved
13100 13102 Know-how protection
13103 19999 Reserved
20000 29999 OEM
30000 30999 DRIVE-CLiQ component power unit
31000 31999 DRIVE-CLiQ component encoder 1
32000 32999 DRIVE-CLiQ component encoder 2
Note
Faults that occur are automatically output as an alarm if the encoder is
parameterized as a direct measuring system and does not intervene in
the motor control.
33000 33999 DRIVE-CLiQ component encoder 3
Note
Faults that occur are automatically output as an alarm if the encoder is
parameterized as a direct measuring system and does not intervene in
the motor control.
34000 34999 Voltage Sensing Module (VSM)
35000 35199 Terminal Module 54F (TM54F)
35200 35999 Terminal Module 31 (TM31)
36000 36999 DRIVE-CLiQ Hub Module
37000 37999 HF Damping Module
