SINAMICS G120 Control Units CU240B-2/CU240E-2
List Manual (LH11), 01/2016, A5E33839529
355
2 Parameters
2.2 List of parameters
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the M coordinate of the 2nd value pair of the friction characteristic.
Dependency: Refer to: p3821, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the M coordinate of the 3rd value pair of the friction characteristic.
Dependency: Refer to: p3822, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the M coordinate of the 4th value pair of the friction characteristic.
Dependency: Refer to: p3823, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the M coordinate of the 5th value pair of the friction characteristic.
Dependency: Refer to: p3824, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the M coordinate of the 6th value pair of the friction characteristic.
Dependency: Refer to: p3825, p3845
p3831[0...n] Friction characteristic value M1 / Friction M1
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 7_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
-1000000.0000 [Nm] 1000000.0000 [Nm] 0.0000 [Nm]
p3832[0...n] Friction characteristic value M2 / Friction M2
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 7_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
-1000000.0000 [Nm] 1000000.0000 [Nm] 0.0000 [Nm]
p3833[0...n] Friction characteristic value M3 / Friction M3
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 7_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
-1000000.0000 [Nm] 1000000.0000 [Nm] 0.0000 [Nm]
p3834[0...n] Friction characteristic value M4 / Friction M4
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 7_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
-1000000.0000 [Nm] 1000000.0000 [Nm] 0.0000 [Nm]
p3835[0...n] Friction characteristic value M5 / Friction M5
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 7_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
-1000000.0000 [Nm] 1000000.0000 [Nm] 0.0000 [Nm]
