SINAMICS G120 Control Units CU240B-2/CU240E-2

List Manual (LH11), 01/2016, A5E33839529

467

2 Parameters

2.2 List of parameters

Description: Display parameter for binary quantity Q = I0 | I1 | I2 | I3 of instance OR 2 of the OR function block.

Description: Setting parameter for the run-time group in which the instance OR 2 of the OR function block is to be called.

Value: 1: Run-time group 1

2: Run-time group 2

3: Run-time group 3

4: Run-time group 4

5: Run-time group 5

6: Run-time group 6

9999: Do not calculate

Description: Setting parameter for the run sequence of instance OR 2 within the run-time group set in p20056.

Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run

sequence value.

Description: Sets the signal source of input quantities I0, I1, I2, I3 of instance OR 3 of the OR function block.

Index: [0] = Input I0

[1] = Input I1

[2] = Input I2

[3] = Input I3

Description: Display parameter for binary quantity Q = I0 | I1 | I2 | I3 of instance OR 3 of the OR function block.

r20055 BO: OR 2 output Q / OR 2 output Q

Access level: 3 Calculated: - Data type: Unsigned32

Can be changed: - Scaling: - Dyn. index: -
