2 Parameters
2.1 Overview of parameters
SINAMICS G120 Control Units CU240B-2/CU240E-2
12 List Manual (LH11), 01/2016, A5E33839529
2.1 Overview of parameters
2.1.1 Explanation of the parameter list
Basic structure of the parameter descriptions
The data in the following example have been chosen at random. The table below contains all
the information that can be included in a parameter description. Some of the information is
optional.
The "List of parameters" (Page 26) has the following structure:
- - - - - - - - - - - - Start of example - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
Description: Text
Value: 0: Name and meaning of value 0
1: Name and meaning of value 1
2: Name and meaning of value 2
etc.
Recommendation: Text
Index: [0] = Name and meaning of index 0
[1] = Name and meaning of index 1
[2] = Name and meaning of index 2
etc.
Dependency: Text
Refer to: pxxxx, rxxxx
Refer to: Fxxxxx, Axxxxx
Note: Information that might be useful.
- - - - - - - - - - - - End of example - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
The individual pieces of information are described in detail below.
pxxxx[0...n] BICO: Full parameter name / abbreviated name
CU/PM variants Access level: 3 Calculated: p0340 = 1 Data type: FloatingPoint32
Can be changed: C(x), U, T Scaling: p2002 Dyn. index: CDS, p0170
Unit group: 6_2 Unit selection: p0505 Func. diagram: 8070
Min Max Factory setting
0.00 [Nm] 10.00 [Nm] 0.00 [Nm]
Bit field: Bit Signal name 1 signal 0 signal FP
00 Name and meaning of bit 0 Yes no 8060
01 Name and meaning of bit 1 Yes no -
02 Name and meaning of bit 2 Yes no 8052
etc.
Danger: Warning: Caution: Safety notices with a warning triangle
Notice: Safety notice without a warning triangle
