SINAMICS G120 Control Units CU240B-2/CU240E-2
List Manual (LH11), 01/2016, A5E33839529
13
2 Parameters
2.1 Overview of parameters
pxxxx[0...n] Parameter number
The parameter number is made up of a "p" or "r", followed by the parameter number and the
index or bit field (optional).
Examples of the representation in the parameter list:
Other examples of notation in the documentation:
The following applies to adjustable parameters:
The parameter value as delivered is specified under "Factory setting" with the relevant unit in
square brackets. The value can be adjusted within the range defined by "Min" and "Max".
The term "linked parameterization" is used in cases where changes to adjustable parameters
affect the settings of other parameters.
Linked parameterization can occur, for example, as a result of the following actions and
parameters:
• Setting the PROFIBUS telegram (BICO interconnection)
p0922
• Setting component lists
p0230, p0300, p0301, p0400
• Automatically calculating and pre-assigning
p0340, p3900
• Restoring the factory settings
p0970
The following applies to display parameters:
The fields "Min", "Max" and "Factory setting" are specified with a dash "-" and the relevant unit
in square parentheses.
• p... Adjustable parameters (read and write)
• r... Display parameters (read only)
• p0918 Adjustable parameter 918
• p2051[0...13] Adjustable parameter 2051, indices 0 to 13
• p1001[0...n] Adjustable parameter 1001, indices 0 to n (n = configurable)
• r0944 Display parameter 944
• r2129.0...15 Display parameter 2129 with bit field from bit 0 (smallest bit) to bit 15
(largest bit)
• p1070[1] Adjustable parameter 1070, index 1
• p2098[1].3 Adjustable parameter 2098, index 1 bit 3
• p0795.4 Adjustable parameter 795, bit 4
Note
The parameter list can contain parameters that are not visible in the expert lists of the particular
commissioning software (e.g. parameters for trace functions).
