2 Parameters
2.1 Overview of parameters
SINAMICS G120 Control Units CU240B-2/CU240E-2
14 List Manual (LH11), 01/2016, A5E33839529
BICO: Full parameter name/Abbreviated name
The following abbreviations can appear in front of the BICO parameter name:
CU/PM variants
Indicates for which Control Units (CU) and/or Power Modules (PM) the parameter is valid. If no
CU or PM is listed, then the parameter is valid for all variants.
The following information relating to "CU" and "PM" can be displayed under the parameter
number:
• BI: Binector Input
This parameter is used for selecting the source of a digital signal.
• BO: Binector Output
This parameter is available as a digital signal for interconnection with other
parameters.
• CI: Connector Input
This parameter is used for selecting the source of an "analog" signal.
• CO: Connector Output
This parameter is available as an "analog" signal for interconnection with other
parameters.
• CO/BO: Connector/Binector Output
This parameter is available as an "analog" and digital signal for interconnection
with other parameters.
Note
A BICO input (BI/CI) cannot be interconnected with just any BICO output (BO/CO, signal
source).
When interconnecting a BICO input using the commissioning software, only the corresponding
possible signal sources are listed.
Function diagrams 1020 ... 1030 explain the symbols for BICO parameters and how to deal
with BICO technology.
Table 2-1 Information in the "CU/PM variants" field
CU/PM variants Meaning
All Control Units have this parameter.
CU240B-2 CU240B-2
CU240B-2_DP CU240B-2 with PROFIBUS interface
CU240E-2 CU240E-2
CU240E-2_DP
CU240E-2 with PROFIBUS interface
CU240E-2_DP_F
CU240E-2 with PROFIBUS interface and extended integrated safety
functions
CU240E-2_F CU240E-2 with extended integrated safety functions
CU240E-2_PN CU240E-2 with PROFINET interface
CU240E-2_PN_F CU240E-2 with PROFINET interface and extended integrated safety
functions
