Siemens CU240B-2 List Manual

SINAMICS G120 Control Units CU240B-2/CU240E-2 List Manual (LH11), 01/2016, A5E33839529
737
3 Function diagrams
3.18 Technology controller
Fig. 3-159 7951 – Fixed value selection direct (p2216 = 1)
- 7951 -
Function diagram
87654321
fp_7951_97_51.vsd
Technology controller
G120 CU240B/E-2
09.12.2015 V4.7.6
Fixed value selection direct (p2216 = 1)
0 0 0 1
0 0 1 0
1 0 0 0
0 1 0 0
(0)
Tec_ctrl sel bit 0
p2220 [C]
(0)
Tec_ctrl sel bit 1
p2221 [C]
(0)
Tec_ctrl sel bit 2
p2222 [C]
(0)
Tec_ctrl sel bit 3
p2223 [C]
r2224
Tec_ctr FixVal eff [%]
Tec_ctr FixVal ZSW
r2225
r2225
+
+
+
+
+
+
.0
Tec_ctr fix val 2 [%]
p2202 [D] (20.00)
Tec_ctrl fix val1 [%]
p2201 [D] (10.00)
Tec_ctr fix val 3 [%]
p2203 [D] (30.00)
Tec_ctr fix val 4 [%]
p2204 [D] (40.00)
Tec_ctr FixVal sel
1 ... 2
p2216 [D] (1)
1
1
1
1
2
2
2
2
[7950]
[7950]
[7950]
[7950]
