2 Parameters
2.2 List of parameters
SINAMICS G120 Control Units CU240B-2/CU240E-2
354 List Manual (LH11), 01/2016, A5E33839529
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 7th value pair of the friction characteristic.
Dependency: Refer to: p3836, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 8th value pair of the friction characteristic.
Dependency: Refer to: p3837, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 9th value pair of the friction characteristic.
Dependency: Refer to: p3838, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 10th value pair of the friction characteristic.
Dependency: Refer to: p3839, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the M coordinate of the 1st value pair of the friction characteristic.
Dependency: Refer to: p3820, p3845
p3826[0...n] Friction characteristic value n6 / Friction n6
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 600.00 [rpm]
p3827[0...n] Friction characteristic value n7 / Friction n7
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 1200.00 [rpm]
p3828[0...n] Friction characteristic value n8 / Friction n8
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 1500.00 [rpm]
p3829[0...n] Friction characteristic value n9 / Friction n9
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 3000.00 [rpm]
p3830[0...n] Friction characteristic value M0 / Friction M0
Access level: 2 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 7_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
-1000000.0000 [Nm] 1000000.0000 [Nm] 0.0000 [Nm]
