SINAMICS G120 Control Units CU240B-2/CU240E-2
List Manual (LH11), 01/2016, A5E33839529
519
2 Parameters
2.2 List of parameters
Description: Setting parameter for the run-time group in which instance PDE 2 of the closing delay device is to be called.
Value: 5: Run-time group 5
6: Run-time group 6
9999: Do not calculate
Description: Setting parameter for the run sequence of instance PDE 2 within the run-time group set in p20337.
Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run
sequence value.
Description: Sets the signal source for the input pulse I of instance PDE 3 of the closing delay device.
Description: Setting parameter for pulse delay time T in milliseconds of instance PDE 3 of the closing delay device.
Description: Display parameter for output pulse Q of instance PDE 3 of the closing delay device.
Description: Setting parameter for the run-time group in which instance PDE 3 of the closing delay device is to be called.
p20337 PDE 2 run-time group / PDE 2 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 7232
Min Max Factory setting
5 9999 9999
p20338 PDE 2 run sequence / PDE 2 RunSeq
Access level: 3 Calculated: - Data type: Unsigned16
Can be changed: T Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 7232
Min Max Factory setting
0 32000 890
p20339 BI: PDE 3 input pulse I / PDE 3 inp_pulse I
Access level: 3 Calculated: - Data type: U32 / Binary
Can be changed: T Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 7232
Min Max Factory setting
- - 0
p20340 PDE 3 pulse delay time in ms / PDE 3 t_del ms
Access level: 3 Calculated: - Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 7232
Min Max Factory setting
0.00 5400000.00 0.00
r20341 BO: PDE 3 output Q / PDE 3 output Q
Access level: 3 Calculated: - Data type: Unsigned32
Can be changed: - Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 7232
Min Max Factory setting
- - -
p20342 PDE 3 run-time group / PDE 3 RTG
Access level: 3 Calculated: - Data type: Integer16
Can be changed: T Scaling: - Dyn. index: -
Unit group: - Unit selection: - Func. diagram: 7232
Min Max Factory setting
5 9999 9999
