3
SINAMICS G120 Control Units CU240B-2/CU240E-2
List Manual (LH11), 01/2016, A5E33839529
555
Function diagrams
Content
3.1 Table of contents 556
3.2 Explanations on the function diagrams 562
3.3 Input/output terminals 567
3.4 PROFIenergy 582
3.5 Communication PROFIdrive (PROFIBUS/PROFINET), EtherNet/IP 585
3.6 Communication fieldbus interface (USS, Modbus) 601
3.7 Internal control/status words 608
3.8 Brake control 627
3.9 Safety Integrated Basic Functions 629
3.10 Safety Integrated Extended Functions 636
3.11 Safety Integrated PROFIsafe 646
3.12 Setpoint channel 649
3.13 Vector control 660
3.14 Vector control, Standard Drive Control (p0096 = 1) 688
3.15 Vector control, Dynamic Drive Control (p0096 = 2) 694
3.16 Technology functions 711
3.17 Free function blocks 714
3.18 Technology controller 735
3.19 Signals and monitoring functions 740
3.20 Diagnostics 754
3.21 Data sets 760
