SINAMICS G120 Control Units CU240B-2/CU240E-2
List Manual (LH11), 01/2016, A5E33839529
353
2 Parameters
2.2 List of parameters
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 2nd value pair of the friction characteristic.
Dependency: Refer to: p3831, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 3rd value pair of the friction characteristic.
Dependency: Refer to: p3832, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 4th value pair of the friction characteristic.
Dependency: Refer to: p3833, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 5th value pair of the friction characteristic.
Dependency: Refer to: p3834, p3845
Description: The friction characteristic is defined by 10 value pairs.
This parameter specifies the n coordinate of the 6th value pair of the friction characteristic.
Dependency: Refer to: p3835, p3845
p3821[0...n] Friction characteristic value n1 / Friction n1
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 30.00 [rpm]
p3822[0...n] Friction characteristic value n2 / Friction n2
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 60.00 [rpm]
p3823[0...n] Friction characteristic value n3 / Friction n3
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 120.00 [rpm]
p3824[0...n] Friction characteristic value n4 / Friction n4
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 150.00 [rpm]
p3825[0...n] Friction characteristic value n5 / Friction n5
Access level: 2 Calculated: p0340 = 1,3,5 Data type: FloatingPoint32
Can be changed: T Scaling: - Dyn. index: DDS, p0180
Unit group: 3_1 Unit selection: p0505 Func. diagram: 7010
Min Max Factory setting
0.00 [rpm] 210000.00 [rpm] 300.00 [rpm]
