3 Function diagrams 3.11 Safety Integrated PROFIsafe
SINAMICS G120 Control Units CU240B-2/CU240E-2
648 List Manual (LH11), 01/2016, A5E33839529
Fig. 3-77 2917 – Manufacturer-specific telegrams
- 2917 -
Function diagram
87654321
fp_2917_97_58.vsd
Safety Integrated PROFIsafe
CU240E-2_DP_F/PN_F
09.12.2015 V4.7.6
Manufacturer-specific telegrams
PZD6
PZD8
PZD9
PZD10
PZD11
PZD13
PZD14
PZD15
PZD16
PZD12
PZD7
PZD5
PZD4
PZD1
PZD2
PZD3
PZD17
PZD18
PZD19
PZD24
PZD26
PZD27
PZD28
PZD29
PZD31
PZD32
PZD30
PZD25
PZD23
PZD22
PZD20
PZD21
900
S_STW1 S_ZSW1
Interconnec-
tion is made
according to
Ps telegram_sel
p60022
Telegram
S_STW5 S_ZSW5
Receive telegram from
PRPFIBUS/PROFINET
Send telegram to
PROFIBUS/PROFINET
