2 Parameters

2.2 List of parameters

SINAMICS G120 Control Units CU240B-2/CU240E-2

504 List Manual (LH11), 01/2016, A5E33839529

Description: Sets the smoothing time constant T in milliseconds of instance PT1 0 of the smoothing element.

Description: Display parameter for the smoothed output quantity Y of instance PT1 0 of the smoothing element.

Description: Setting parameter for the run-time group in which instance PT1 0 of the smoothing element is to be called.

Value: 5: Run-time group 5

6: Run-time group 6

9999: Do not calculate

Description: Setting parameter for the run sequence of instance PT1 0 within the run-time group set in p20248.

Note: The function blocks with a lower run sequence value are calculated before function blocks with a higher run

sequence value.

Description: Sets the signal source of input quantity X and of setting value SV of instance PT1 1 of the smoothing element.

Index: [0] = Input X

[1] = Setting value SV

p20246 PT1 0 smoothing time constant in ms / PT1 0 T_smooth ms

Access level: 3 Calculated: - Data type: FloatingPoint32

Can be changed: T Scaling: - Dyn. index: -
