Setting up the machine
2.7 Work offsets
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
101
You can save the workpiece zero, for example, in the coarse offset, and then store the offset
that occurs when a new workpiece is clamped between the old and the new workpiece zero
in the fine offset.
Note
Deselect fine offset
You have the option of deselecting the fine offset via machine data
$MN_MM_FRAM_FINE_TRANS.
See also
Actual value window (Page 33)
2.7.1 Display active zero offset
The following work offsets are displayed in the "Work Offset - Active" window:
● Work offsets, for which active offsets are included, or for which values are entered.
● adjustable work offsets
● Total work offset
This window is generally used only for monitoring.
The availability of the offsets depends on the setting.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
