Program management
13.4 Creating a directory/program/job list/program list
Milling
504 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
13.4.2 Creating a new workpiece
You can set up various types of files such as main programs, initialization files, tool offsets,
etc. in a workpiece.
Note
Additional workpiece directories cannot be created within a workpiece directory (WPD).
Proceed as follows
1. Select the "Program manager" operating area.
2. Select the desired storage location and position the cursor on the
folder, in which you would like to create a workpiece.
3. Press the "New" and "Workpiece" softkeys.
The "New workpiece" window appears.
4. If necessary, select a template if any are available.
5. Enter the desired workpiece name, select a template, if necessary,
and press the "OK" softkey.
The name may be a maximum of 24 characters long.
You can use any letters (except umlauts), digits or the underscore
symbol (_).
The directory type (WPD) is set by default.
A new folder with the workpiece name will be created.
The "New G code program" window will open.
6. Press the "OK" softkey again if you want to create the program.
The program will open in the editor.
