Easy Message (828D only)
16.4 Setting-up events
Milling
546 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
5. In the area "send SMS for the following events" area, activate the
appropriate checkbox and when required, enter the desired value (e.g.
the unit quantity, which when it is reached, a notification should be
sent).
- OR -
Press the "Default" softkey.
The appropriate window is opened and displays the default values.
6. Press the "Send test message" softkey.
An SMS message with predefined text is sent to the specified
telephone number.
Editing user data and events
1. Select the user whose data you want to edit and press the "Edit"
softkey.
The input fields can be edited.
2. Enter new data and activate the desired settings.
- OR -
Press the "Default" softkey to accept the default values.
16.4 Setting-up events
In the "Send SMS for the following events" area, select the events using the check box,
which when they occur, an SMS is sent to the user.
● Programmed messages from the part program (MSG)
In the part program, program an MSG command via which you receive an SMS.
Example: MSG ("SMS: An SMS from a part program")
● Select the following events using the <SELECT> key
– The workpiece counter reaches the following value
An SMS is sent if the workpiece counter reaches the set value.
– The following program progress is reached (percent)
An SMS is sent if, when executing a part program, the set progress is reached.
– Actual NC program reaches runtime (minutes)
An SMS is sent after the set runtime has been reached when executing an NC
program.
– Tool usage time reaches the following value (minutes)
An SMS is sent if the usage time of the tool reaches the set time when executing a
part program (derived from $AC_CUTTING_TIME).
● Messages/alarms from the Tool Manager
An SMS is sent if messages or alarms are output to the Tool Manager.
