Program management
13.14 V24
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
529
13.14.2 Setting V24 in the program manager
V24 setting Meaning
Protocol The following protocols are supported for transfer via the V24 interface:
RTS/CTS (default setting)
Xon/Xoff
Transfer It is also possible to use a secure protocol for data transfer (ZMODEM
protocol).
Normal (default setting)
secure
For the selected interface, secure data transfer is set in conjunction
with handshake RTS/CTS.
Baud rate Transfer rate: Transfer rates of up to 115 kbaud can be selected. The
baud rate that can be used depends on the connected device, the
cable length and the general electrical conditions.
110
....
19200 (default)
...
115200
Archive format
Punched tape format (default setting)
Binary format (PC format)
V24 settings (details)
Interface
COM1
Parity Parity bits are used for error detection: The parity bits are added to the
coded characters to make the number of positions set to "1" an uneven
number (uneven parity) or to an even number (even parity).
None (default setting)
Odd
Even
Stop bits Number of stop bits for asynchronous data transfer.
1 (default)
2
Data bits Number of data bits for asynchronous data transfer.
5 bits
...
-8 bits (default setting)
XON (hex) Only for punched tape format
XOFF (hex) Only for punched tape format
