Creating G code program
6.9 Calling technology functions
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
213
6.9.5 Additional functions in the input screens
Selection of units
If, for example, the unit can be switched in a field, this is highlighted as soon as the
cursor is positioned on the element. In this way, the operator recognizes the
dependency.
The selection symbol is also displayed in the tooltip.
Display of abs or inc
The abbreviations "abs" and "inc" for absolute and incremental values are displayed behind
the entry fields when a switchover is possible for the field.
Help screens
2D and 3D graphics or sectional views are displayed for the parameterization of the cycles.
Online help
If you wish to obtain more detailed information about certain G code commands or cycle
parameters, then you can call a context-sensitive online help.
