Programming technological functions (cycles)
8.7 Further cycles and functions ShopMill
Milling
434 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
8.7.14 Obstacle
Function
If there is an obstacle between 2 position patterns, it can be crossed. The height of the
obstacle can be programmed absolutely or incrementally.
If all positions in the 1st pattern have been machined, the tool axis travels with rapid traverse
to a height corresponding to the obstacle height + safety clearance. The new position is
approached with rapid traverse at this height. The tool axis then approaches a position
according to Z0 of the position pattern + safety clearance with rapid traverse.
Procedure
1. The ShopMill program to be edited has been created and you are in
the editor.
2. Press the "Drilling" softkey.
3.
Press the "Positions" and "Obstacle" softkeys.
The "obstacle" input window opens.
Note
Obstacles are only taken into consideration if they lie between 2 position patterns. If the tool
change point and the programmed retraction plane are positioned below the obstacle, the
tool travels to the retraction plane height and on to the new position without taking the
obstacle into account. The obstacle must not be higher than the retraction plane.
Parameter Description Unit
Z0 Obstacle height (abs or inc)
