Creating a ShopMill program

7.17 Example, standard machining

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

247

7.17.1 Workpiece drawing































6WDUWSXQNW





















5













7LHIH



























;

<



























    



7.17.2 Programming

1. Program header

1. Specify the blank.

Measurement unit mm

Work offset G54

Blank Cuboid

X0 -2.5 abs

Y0 -2.5 abs

X1 182.5 abs

Y1 182.5 abs

ZA 1 abs
