17.3 Activating and deactivating a device

Milling

Operating Manual, 03/2010, 6FC5398-7CP20-1BA0

553

17.3 Activating and deactivating a device

Status Meaning

Device activated

System waiting for PLC checkback signal

Device faulty

Interface error in the communication module

Procedure

1. Easy Extend is opened.

2 You can select the desired device in the list with the <Cursor up> and

<Cursor down> keys.

3. Position the cursor on the device option for which the function has

been unlocked and press the "Activate" softkey.

The device is marked as activated and can now be used.

4. Select the desired activated device and press the "Deactivate" softkey

to switch the device off again.
