Program management
13.1 Overview
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
499
Procedure
1. The local drive is selected.
2. Position the cursor on the main directory.
3. Press the "New" and "Directory" softkeys.
The "New Directory" window opens.
4. In the "Name" entry field, enter "mpf.dir", "spf.dir" and "wks.dir" and
press the "OK" softkey.
The directories "Part programs", "Subprograms" and "Workpieces" are
created below the main directory.
13.1.3 USB drives
USB drives enable you to exchange data. For example, you can copy to the NC and execute
programs that were created externally.
NOTICE
Execution from USB FlashDrive
Direct execution from the USB FlashDrive is not recommended.
Procedure
1. Select the "Program manager" operating area.
2. Press the "USB" softkey.
Note
The "USB" softkey can only be operated when a USB FlashDrive is inserted in the front
interface of the operator panel.
