Tool management
12.5 Tool list
Milling
480 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Multiple load points
If you have configured several loading points for a magazine, then the "Loading Point
Selection" window appears after pressing the "Load" softkey.
Select the required loading point and confirm with "OK".
Unloading tools
1. Place the cursor on the tool that you would like to unload from the
magazine and press the "Unload" softkey.
2. Select the required load point in the "Loading Point Selection" window.
3. Confirm your selection with "OK".
- OR -
Undo your selection with "Cancel".
12.5.7 Selecting a magazine
You can directly select the buffer memory, the magazine, or the NC memory.
Procedure
1. The tool list is opened.
2. Press the "Magazine selection" softkey.
If there is only one magazine, you will move from one area to the next
(i.e. from the buffer memory to the magazine, from the magazine to
the NC memory, and from the NC memory back to the buffer memory)
each time you press the softkey. The cursor is positioned at the
beginning of the magazine each time.
- OR -
If there is more than one magazine, the "Magazine Selection" window
opens. Position the cursor on the desired magazine in this window
and press the "Go to" softkey.
The cursor jumps directly to the beginning of the specified magazine.
