Program management
13.1 Overview
Milling
498 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
13.1.1 NC memory
The complete NC working memory is displayed along with all tools and the main programs
and subroutines.
You can create further subdirectories here.
Proceed as follows
1. Select the "Program manager" operating area.
2. Press the "NC" softkey.
13.1.2 Local drive
Workpieces, main and subprograms are displayed that are saved in the user memory of the
CF-Card or on the local hard disk.
For archiving, you have the option of mapping the structure of the NC memory system or to
create your own archiving system.
You can create any number of subdirectories here, in which to store any files (e.g. text files
with notes).
Software options
To display the "Local drive" softkey, you require the option "Additional 256
MB HMI user memory on CF Card of the NCU" (not for SINUMERIK Operate
on PCU50 or PC/PG).
Procedure
1. Select the "Program manager" operating area.
2. Press the "Local drive" software key.
On the local drive, you have the option of mapping the directory structure of the NC memory.
This also simplifies the search sequence.
