Setting up the machine
2.7 Work offsets
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
103
Work offsets
Cycle reference Displays the additional work offsets programmed with
$P_CYCFRAME.
Total WO Displays the active work offset, resulting from the total of all work
offsets.
Procedure
1. Select the "Parameter" operating area.
2 Press the "Work offset" and "Overview" softkeys.
The "Work Offsets - Overview" window opens.
2.7.3 Displaying and editing base zero offset
The defined channel-specific and global base offsets, divided into coarse and fine offsets,
are displayed for all set-up axes in the "Work offset - Base" window.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
Procedure
1. Select the "Parameter" operating area.
2. Press the "Work offset" softkey.
3. Press the "Base" softkey.
The "Work offset - Base" window is opened.
4. You can edit the values directly in the table.
