Programming technological functions (cycles)
8.2 Milling
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
305
Parameter Description Unit
X0
Y0
Z0
The positions refer to the reference point:
Reference point X – (for single position only)
Reference point Y – (for single position only)
Reference point Z – (for single position only)
mm
mm
mm
∅ Diameter of blank spigot mm
N Number of edges
SW or L Width across flats or edge length
α0 Angle of rotation Degrees
R1 or FS1 Rounding radius or chamfer width
Z1 Multi-edge depth (abs) or depth in relation to Z0 (inc) - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
DXY
Maximum plane infeed
Maximum plane infeed as a percentage of the cutting tool diameter
- (only for ∇ and ∇∇∇)
mm
%
DZ Maximum depth infeed - (only for ∇ and ∇∇∇) mm
UXY Plane finishing allowance - (only for ∇, ∇∇∇ and ∇∇∇ edge) mm
UZ Depth finishing allowance – (only for ∇ and ∇∇∇) mm
FS Chamfer width for chamfering - (for chamfering only) mm
ZFS Insertion depth of tool tip (abs or inc) - (for chamfering only) mm
%
8.2.7 Longitudinal groove (SLOT1)
Function
You can mill any longitudinal groove with the "longitudinal groove" milling function.
The following machining methods are available:
● Mill longitudinal groove from solid material.
● Pre-drill longitudinal groove in the center first if, for example, the milling cutter does not
cut in the center (program the drilling, rectangular pocket and position program blocks in
succession).
Depending on the dimensions of the longitudinal groove in the workpiece drawing, you can
select a corresponding reference point for the longitudinal groove.
Approach/retraction
1. The tool moves at rapid traverse to the retraction plane and infeeds at safety clearance.
2. The tool is inserted into the material according to the chosen strategy.
3. The longitudinal slot is always machined with the chosen machining type from inside out.
4. The tool moves back to the safety clearance at rapid traverse.
