Programming technological functions (cycles)
8.5 Contour turning - only for G code programs
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
403
8.5.12 Plunge turning residual material (CYCLE952)
Function
The "Plunge turning residual material" function is used when you want to machine the
material that remained after plunge turning.
For a G code program, select the function in the screen. Material that remains as part of the
finishing allowance is not residual material. The "Plunge turning residual material" function
allows you to remove unwanted material with a suitable tool.
The "Plunge turning residual material" function is a software option.
Procedure
1. The part program to be executed has been created and you are in the
editor.
2. Press the "Turning" and "Contour turning" softkeys.
3. Press the "Plunge turning residual material" softkey.
The "Plunge turning residual material" input window opens.
Parameters, G code program
PRG Name of the program to be generated
PL Machining plane
RP Retraction plane - (only for
longitudinal machining
direction)
mm
SC Safety clearance mm
F Feedrate mm/min
Residual
material
With subsequent residual material removal
Yes
No
CONR Name to save the updated unmachined-part
contour for residual material removal - (only
"Yes" for residual material removal)
