Setting up drives
14.2 Setting up drives
Milling
532 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
14.2 Setting up drives
The "Set-up drives" window is available in the "Startup" operating area for configuration.
File
The created configuration data is stored in the "logdrive.ini" file. This file is located in the
/user/sinumerik/hmi/cfg directory.
General information
Entry Meaning
No drive No drive defined.
USB local Access to the USB memory medium is only realized via the
TCU to which it is connected.
USB drives are automatically identified if the memory medium
is inserted when SINUMERIK Operate powers-up.
USB global All of the TCUs in the plant network can access the USB
memory medium.
- USB global is not possible under Windows!
NW Windows Network drive
Type
Local drive Local drive
Hard disk or user memory on the CompactFlash Card
Front USB interface that is located at the front of the operator panel.
X203/X204
USB interface X203/X204 that is located at the rear of the
operator panel.
Connection
X204 For SIMATIC Thin Client the USB interface is X204.
Device Names of the TCU to which the USB storage medium is
connected, e.g. tcu1. The NCU must already know the TCU
name.
Partition Partition number on the USB memory medium, e.g. 1.
If a USB hub is used, specify the USB port of the hub.
Path
Start direct directory of the data carrier that is connected
via the local drive.
Network path to a directory that has been released in the
network. This path must always start with "//", e.g.
//Server01/share3.
Access level Assign access rights to the connections: From protection level
7 (key switch position 0) to protection level 1 (password:
Manufacturer).
The particular assigned protection level applies to all
operating areas.
Softkey text Two lines are available as labeling text for the softkey. %n is
accepted as a line separator.
If the first line is too long, then it is automatically separated
into several lines.
If a blank is present, then this is used as line separator.
Softkey icon No icon No icon is displayed on the softkey.
