Program management
13.2 Opening and closing the program
Milling
500 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
13.2 Opening and closing the program
To view a program in more detail or modify it, open the program in the editor.
With programs that are in the NCK memory, navigation is already possible when opening.
The program blocks can only be edited when the program has been opened completely. You
can follow the opening of the program in the dialog line.
With programs that are opened via local network, USB FlashDrive or network connections,
navigation is only possible when the program has been opened completely. A progress
message box is displayed when opening the program.
Procedure
1. Select the "Program manager" operating area.
2. Select the desired storage location and position the cursor on the
program that you would like to edit.
3. Press the "Open" softkey.
- OR -
Press the <INPUT> key.
- OR -
Press the <Cursor right> key.
- OR -
Double-click the program.
The selected program is opened in the "Editor" operating area.
4. Now make the necessary program changes.
5. Press the "NC Select" softkey to switch to the "Machine" operating
area and begin execution.
When the program is running, the softkey is deactivated.
