User variables
10.7 Searching for user data
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
447
10.7 Searching for user data
You can search for R parameters and user data.
Procedure
1. Select the "Parameter" operating area.
2. Press the "R parameters", "Global GUD", "Channel GUD", "Local
GUD" or "Program PUD" softkeys to select the list in which you would
like to search for user data.
3. Press the "Search" softkey.
The "Search for R Parameters" or "Search for User Data" window
opens.
4. Enter the desired search term and press "OK".
The cursor is automatically positioned on the the R parameter or user
data you are searching for, if they exist.
10.8 Defining and activating user variables
By editing a DEF/MAC file, you can alter or delete existing definition/macro files or add new
ones.
Proceed as follows
1. Select the "Startup" operating area.
2. Press the "System data" softkey.
3. In the data tree, select the "NC data" folder and then open the
"Definitions" folder.
4. Select the file you want to edit.
5. Double-click the file.
- OR -
