Machining the workpiece
4.11 Displaying G Functions and Auxiliary Functions
Milling
Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
165
The G groups selection displayed in the "G Functions" window may differ.
Machine manufacturer
Please refer to the machine manufacturer's specifications.
References
For more information about configuring the displayed G groups, refer to the following
document:
Commissioning Manual SINUMERIK Operate (IM9) / SINUMERIK 840D sl
4.11.2 All G functions
All G groups and their group numbers are listed in the "G Functions" window.
Within a G group, only the G function currently active in the controller is displayed.
Additional information in the footer
The following additional information is displayed in the footer:
● Current transformations
Display Meaning
TRANSMIT Polar transformation active
TRACYL Cylinder surface transformation active
TRAORI Orientation transformation active
TRAANG Inclined axis transformation active
TRACON Cascaded transformation active
For TRACON, two transformations (TRAANG and TRACYL or TRAANG and
TRANSMIT) are activated in succession.
● Current zero offsets
● Spindle speed
● Path feedrate
● Active tool
