Page #338 background imageLoading...
Page #338 background image
Programming technological functions (cycles)
8.3 Contour milling
Milling
338 Operating Manual, 03/2010, 6FC5398-7CP20-1BA0
Procedure
1. The subprogram to be edited has been created and you are in the
editor.
2. Press the "Contour milling" softkey.
3. Press the "Contour" and "Contour call" softkeys.
The "Contour Call" input window opens.
4. Assign parameters to the contour selection.
Parameter Description Unit
Contour selection
Contour name
Labels
Subprogram
Labels in the subprogram
Contour name CON: Contour name
Labels
LAB1: Label 1
LAB2: Label 2
Subprogram PRG: Subprogram
Labels in the
subprogram
PRG: Subprogram
LAB1: Label 1
LAB2: Label 2
8.3.7 Path milling (CYCLE72)
Function
You can mill along any programmed contour with the "Path milling" cycle. The function
operates with cutter radius compensation. Machining can be performed in either direction,
i.e. in the direction of the programmed contour or in the opposite direction.
It is not imperative that the contour is closed. You can perform any of the following
operations:
Inside or outside machining (on left or right of the contour).
Machining along center-point path.
For machining in the opposite direction, contours must not consist of more than 170 contour
elements (incl. chamfers/radii). Special aspects (except for feed values) of free G code input
are ignored during path milling in the opposite direction to the contour.
